FEATURES

IP65 Outdoor Rated Par Luminaire
Special White Marine Grade Exterior Coating
Rugged Die-Cast Aluminum Exterior with Dual Yoke / Floor Stand
(18) 12W 6-in-1 RGBAW+UV LEDs
23° Beam Angle
395nm UV Wavelength
Electronic Strobe and Variable Dimming Curve Modes
Manual and DMX-512 Control
RDM (Remote Device Management) Support
Hard Wired (Bare Wire) IP Rated Power/Data Combo In/Out Cables Attached

SPECIFICATIONS

SOURCE

(18) 12W 6-in-1 RGBAW+UV LEDs
100,000 Hour Average LED Life*
*Lamp Life may vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control and Dimming.


PHOTOMETRIC DATA

coming soon


EFFECTS

Electronic Strobe
Variable Dimming Curves Modes
Internal Color and Color Chase Macros


CONTROL / CONNECTIONS

Manual and DMX-512 Control
(4) DMX Channel Modes (6 / 7 / 8 / 12)
(4) Button Touch LCD Menu Display
Hard Wired (Bare Wire) IP Rated Power/Data Combo In/Out Cables Attached
With Wired Digital Communication Network


SIZE / WEIGHT

Length: 365mm (14.4”)
Width: 125mm (4.9”)
Vertical Height: 365mm (14.4”)
Weight: 9.5 kg (21.0 lbs.)


ELECTRICAL / THERMAL

AC 110-250V - 50/60Hz
220W Max Power Consumption
-15°C to 45°C (5°F to 113°F)
UV Wavelength: 395nm
