FEATURES

150W RGBMA LED Engine
ColourTune Technology Software Integration
5,700 Total Fixture Lumen Output (Sphere)
Field Replaceable Lenses
Stand-Alone Control with Touch Encoder and OLED Display
Smooth 16-bit Selectable Dimming Modes and Curves
RDM (Remote Device Management)
NFC & Aria x2 Wireless Device Management
6.25" Gel Frame and Four Lenses (10°, 22°, 30°, 55°) Included
IP65 Rated





SOURCE

150W 6000K RGBMA LED Engine
30,000 Hour Average LED Life*
*Lamp Life may vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control and Dimming.





PHOTOMETRIC DATA

Total Lumen Output:
5,700 (Integrating Sphere)
TBA (Goniometer)
CRI 94.9
TLCI 95





INCLUDED LENSES

VNSP (10°)
NSP (22°)
MFL (30°)
WFL (55°)





EFFECTS

Variable Strobe Rate: 1- 20Hz
Dim-to-Warm/ Red Shift Emulation
Variable 16-bit Dimming Modes and Curves





COLOR

High Brightness and High Fidelity Output Options
RGBMA Color Array
CMY Emulation
16bit Fully Variable CCT 2400K - 8500K
Green/Magenta Shift
Virtual Gel Swatch Book





CONTROL / CONNECTIONS

8 DMX Channel Modes (1, 4, 6, 10, 11, 19, 9, 15)
Manual and DMX Controlled Dimmer and Color
Single Touch Bar Encoder
4 Button Control Panel, LED Display
RDM (Remote Device Management)
Aria x2 Wireless Device Management
NFC Configuration
IP65 5pin DMX and IP65 Locking Power Cable In/Out





SIZE / WEIGHT

Length: 254mm (10”)
Length (Yoke 0°): 362mm (14.25)
Width: 236mm (9.3")
Height (Fixture Body): 183mm (7.2")
Height (Yoke 90°): 312mm (12.3")
Weight: 5.4kg (11.9 lbs)





ELECTRICAL / THERMAL

AC 100-240V - 50/60Hz
200W Max Power Consumption
Power Thru Capacity: 10A (6 units @115V, 12 units @240V)
5°F to 113°F (-15°C to 45°C)
BTU/hr (+/- 10%) 682





INCLUDED ITEMS

Gel Frame
4 Lenses (10°, 22°, 30°, 55°)
IP65 Locking Power Cable





OPTIONAL ITEMS

6.25" Barndoors
Omega Bracket
1236300104 4 Wire Hardwire Installation Plate (HWP404)
1236300105 2 Wire Hardwire Installation Plate (HWP202)
